SUV-3000 UV Radiation Safety Measurement System
SUV-3000 UV radiation safety measurement system is an innovated product, designed according to the requirements of non-measurements of non-directional lights of EUP and UVA+UVB and UVC limit requirements for CFL and similar products.
- Parameter
- Guide
Function:SUV-3000 UV radiation safety measurement system is an innovated product, designed according to the requirements of non-measurements of non-directional lights of EUP and UVA+UVB and UVC limit requirements for CFL and similar products. The system is special for the UV measurement required in EUP NO.32 directive, and meets the requirements of EN62471-2008 "Photobiological Safety of Lamp and Lamp system".
Specifications:
>> Spectral Range: 200nm-800nm
>> Irradiance repeatability:2.0%(UV), 0.5%(VIS)
>> Wavelength accuracy:
0.1nm
>> Spectral interval: 1nm, 5nm
>> Photometric linearity: 0.1
>> Dynamic range: 1010
>> Stray Light:
10-6(UV Photobiological spectral range)
Features:
>> Specialized in UV radiation measurement
>> Good performance in Stray light elimination
>> High sensitivity
Measurement Items:
>> Effective UV radiation (UVA+UVB+UVC) of CFL lighting products.
>> Effective UV radiation of halogen lamp and luminaire.
>> UV irradiance and effective UV irradiance, effective irradiance(UVA, UVB and UVC) of household appliances with UV radiation.
>> Photometric and colormetric parameters of light source and luminaire.
